Exmark / Toro 117-1197 Genuine OEM Starter Solenoid

The Exmark / Toro 117-1197 Starter Solenoid is a genuine OEM replacement electrical solenoid used on many Exmark and Toro mower applications. This solenoid links the battery, starter, and wiring harness to help control starter engagement when the key switch or start circuit is activated.

This is one of the most common starter solenoids used across Exmark mower families and is commonly searched as an Exmark 117-1197 solenoid, Toro 117-1197 solenoid, Exmark starter solenoid, Toro starter relay, Exmark Quest solenoid, Exmark Radius solenoid, or zero-turn mower starter solenoid.

Exmark / Toro part number 117-1197 replaces 1-513075 where specified. Always verify your full model number, serial number, original solenoid part number, wiring layout, terminal configuration, and parts diagram before ordering.

Product Details

Easy Model Fitment Guide

Use the dropdowns below to quickly check common model families. Serial ranges have been grouped to make fitment easier to read. This is a where-used reference list, not a guarantee by model name alone. Always confirm your exact model and serial number in the Exmark or Toro parts lookup before ordering.

Important: This is a where-used reference list. Starter solenoid fitment depends on the exact model, serial range, wiring layout, mounting location, terminal configuration, and parts diagram. Always match your original part number before ordering.

Key Features

• Genuine OEM Exmark / Toro starter solenoid
• OEM part number 117-1197
• Replaces Exmark / Toro 1-513075 where specified
• Common solenoid used throughout many Exmark mower applications
• Connects the starter, battery, and wiring harness in compatible starting systems
• Fits select Exmark Quest, Radius, Turf Tracer, Vantage, Explorer, Lazer Z, Metro, Pioneer, and Viking models where specified
• Fits select Toro TimeCutter and Titan applications where specified
• OEM quality for precise compatibility and reliable electrical performance
• Factory-correct replacement when listed in your parts diagram

Why Choose an OEM Exmark / Toro Solenoid?

A starter solenoid must match the correct terminal layout, mounting style, wiring harness connection, and electrical requirements for your mower. Using the wrong solenoid can cause no-start issues, wiring damage, intermittent cranking, blown fuses, or unsafe operation.

Genuine Exmark / Toro 117-1197 is built for compatible mower starting systems. When your parts diagram lists 117-1197 or the replaced part number 1-513075, this OEM solenoid is the correct replacement.

• Correct OEM fit when specified by the parts lookup
• Designed for compatible Exmark and Toro starting circuits
• Helps restore reliable starter engagement
• Reduces guesswork compared to universal electrical solenoids
• OEM quality for consistent fit and performance

When to Replace a Starter Solenoid

Replace the starter solenoid if the mower clicks but does not crank, cranks intermittently, has damaged terminals, shows heat damage, or if testing confirms the solenoid is not passing power correctly. Always inspect the battery, cables, grounds, fuses, key switch, safety switches, and starter before replacing electrical parts.

• Mower clicks when the key is turned but will not crank
• Starter only engages sometimes
• Solenoid terminals are corroded, loose, burnt, or damaged
• Battery and starter test good but power is not passing through the solenoid
• Wiring harness connector is damaged or overheated
• Your parts diagram lists 117-1197 or 1-513075

Important Fitment Notes

• This listing is for Exmark / Toro part number 117-1197
• Replaces 1-513075 where specified
• Verify your original solenoid part number before ordering
• Confirm terminal layout, mounting location, wiring connections, and model serial range
• Do not order by mower model name alone
• Inspect battery cables, ground cable, wiring harness, fuse holder, key switch, safety switches, and starter during diagnosis

Pre-Purchase Checklist

Before ordering Exmark / Toro 117-1197, confirm:

• Your original solenoid part number is 117-1197 or 1-513075
• Your mower model and serial number match the parts lookup
• Your wiring layout and terminal configuration match this solenoid
• Your battery is fully charged and tests good
• Your battery cables, grounds, fuses, key switch, safety switches, and starter have been inspected

Installation and Service Notes

Starter solenoid replacement should be performed with the mower parked on level ground, key removed, parking brake engaged, blades disengaged, and the battery disconnected. Disconnect the negative battery cable first and reconnect it last.

• Take a photo of the wiring before removing the old solenoid
• Label wires if needed to avoid incorrect installation
• Inspect terminals and wiring connectors for corrosion, heat damage, or looseness
• Clean battery cable ends and grounds before reassembly
• Install the solenoid in the correct mounting position
• Reconnect wires to the correct terminals
• Reconnect the battery and test starter operation safely

Part Number / Search Terms

Exmark / Toro 117-1197 may also be searched as:

• Exmark 117-1197
• Toro 117-1197
• 1171197
• Exmark 1-513075
• Toro 1-513075
• 1513075
• Exmark starter solenoid
• Toro starter solenoid
• Exmark solenoid relay
• Toro solenoid relay
• Exmark Quest solenoid
• Exmark Radius solenoid
• Exmark Turf Tracer solenoid
• Exmark Vantage solenoid
• Exmark Lazer Z solenoid
• Exmark Metro solenoid
• Exmark Viking solenoid
• Toro TimeCutter solenoid
• Toro Titan solenoid
• zero turn starter solenoid
• mower starter solenoid
• OEM Exmark electrical parts
• OEM Toro electrical parts
