Cub Cadet Pro Z 160 L KW

Cub Cadet Pro Z 160 L KW

Product Number: 53TIEHRU050

Have Questions?

Our experts are here to answer your questions!

515-265-8889   Contact Us

Product Description:

Commercial-grade 23.5 HP Kawasaki engine.

60-inch 10-gauge steel commercial deck with top, bottom and side reinforcements for added durability.

12cc commercial-grade transmission ensures optimal blade tip speed and superior quality of cut at speeds up to 9.5 mph.

Standard high-back suspension seat for all-day comfort.


Specifications:

STEERING: Lap Bar 3/4 length padded bars w/tooless quick adjust dial.

ROPS: 2" x 2" spring-latch tool-less foldable 3 position.

Front Axle / Yokes: 2" x 3" solid steel and 3/8" thick steel with sealed ball bearing front yokes.

Rear Bumper: 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch.

Frame: Fully welded, full-legnth 12ga. channel frame with 14ga. reinforcements.

DIMENSIONS:L / W / H with discharge chute UP and ROPs DOWN.
80" L x 62" W x 48" H.

Weight (approx): 1030 lbs.

Seat Type: High-back suspension with seat belt, adjustable arm rests and 6" seat travel.

Front Tires: 13" x 6.5" - 6" (smooth).

Park Brake / Braking: Intergrated system in Lap Bars for ease of use.

Throttle/PTO/Key Switch: HD Low-profile throttle lever, sealed key switch & electronic fingertip engagement pto.

Rear Tires: 23" x 10.5" - 12" (Turf Master).

PTO Clutch: Warner Clutch - 125 ft lb.

Safety Systems: Operator presence.

MOWER DECK Spindle Construction: 5" sealed cast aluminum housing (maintenance-free).

Deck Blades: 3 high-lift Marbain® blades / 18,500 fpm (approx.).

Top Reinforcement(s): 2ga. and 11 ga. top plate.

Trim-Side Wear Guard: 3/4" Thick UHMW-PE Replaceable Trim-side Wear Guard.

Discharge Chute: High-density, impact-resistant rubber.

Deck Size/Type: 60" FABRICATED DECK.

Bottom Reinforcement: 7ga. (.175") steel.

Leading Edge Reinforcement: 1/4" (.250") steel.

Side Construction: 5/16"(.313) steel on trim and discharge sides.

Deck Height Adjustment: Hand Lever / 15 position / spring assist.

Deck Material: Fully welded 10ga. (.135") steel deck shell with reinforcements totaling .560"

Cutting Height: 1" - 5".

Anti-Scalping: 2 Front HD w/ Bushings & Grease Zerk.

Deck Style/Construction: Floating, fabricated 10ga. (.135”) steel shell (e-coated).

Cup Holder: Intergrated into Side Pod.

Hour Meter: Standard electronic.

WARRANTY: 2-year limited commercial warranty (no hour limitations) or 4-year/500-hour limited residential warranty.

Ground Speed: 9.5mph fwd. / 4.5mph rev.

Horsepower / CC's: 23.5hp - 726cc

Engine Type: Kawasaki FX FX730v.

Fuel Capacity: Twin tanks - 3.5 gallon ea. (7 gallon total) with oversized filler opening
.
Transmission; 12cc Hydro-Gear® ZT 3400 with charge pumps
Type: Zero-Turn
Brand: Cub Cadet
