Cub Cadet PRO Z 560 L KW 53TIHJTV050

Cub Cadet PRO Z 560 L KW 53TIHJTV050

Product Number: 53TIHJTV050

Not Available Online, Please Contact Us.

Have Questions?

Our experts are here to answer your questions!

515-265-8889   Contact Us

Type: Non-Current Models
Brand: Cub Cadet

SET UP AND PREP FEES MAY APPLY

27 HP Kawasaki FX850v (852cc) engine and 12cc Parker HTJ transmission

60” triple-7-gauge fabricated steel cutting deck with top, bottom and side reinforcements

3-year limited commercial warranty (no hour limitations) and 5 year / 1,750 hour limited deck construction warranty



Engine
  • Engine Brand:  Kawasaki®
  • Engine Model:  FX850V-HS
  • Engine Displacement:  852cc
  • Engine Output:  27 HP
  • Fuel Tank Capacity:  Twin 7.45 gal. tanks (14.9 gal. total) with dial gauge



Drive System
  • Transmission:  Parker HTJ Series 12cc pump / 260cc wheel motor
  • Forward Speed:  10 mph
  • Reverse Speed:  5 mph



Cutting Deck
  • Deck Cutting Width:  60-in
  • Deck Material:  fabricated 7ga. (.187”) steel shell
  • Deck Engagement (PTO):  electronic fingertip engagement pto
  • Deck Construction:  7ga. top plate 7ga. bottom reinforcement ¼” rolled leading edge
  • Blade(s):  3 high-lift Marbain® blades / 18,500 fpm (approx.)
  • Cutting Height Range:  1" - 5"
  • Anti-Scalping:  2 Front HD w/ Bushings & Grease Zerk
  • Deck Positions:  Foot pedal with spring assist 16 Positions



Chassis
  • Frame:  Fully welded, full-length 3/8 x 5" laser cut steel / integrated tie-down slots
  • Front Axle(s):  2" x 3" solid axle tube and 1/2" thick steel front yokes
  • Front Tires:  13" x 6.5" - 6" (smooth)
  • Rear Tires:  24" x 12" - 12" (Turf Tread)
  • Tire Tread:  Turf Tread
  • ROPS:  2" x 2" quick-latch tool-less foldable 3 position
  • Bumper:  5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch



Controls
  • Steering Control:  High Performance & Speed Control



Comfort
  • Seat Type:  Cushion
  • Arm Rests:  Standard
  • Seat Suspension:  High-back dial suspension with EVC, with seatbelt
  • Seat Adjustment:  Angle back adjust



Dimensions
  • Dimensions:  L/W/H 84" L x 62" W x 50" H
  • Weight (approx.):  1324 lbs.



Additional Specifications
  • Hour Meter:  Standard electronic
  • Discharge Chute:  High-density, impact-resistant rubber
  • Cup Holder:  Intergrated into Side Pod
  • Model Number:  53TIHJTV050



Warranty
  • Deck Shell Warranty:  5 year / 1,750 hour limited deck construction warranty
  • Commercial Warranty:  3 year / no hour limit commercial warranty
