Vertex X-Series with 35 HP* Kawasaki FX1000V Engine and 60" UltraCut Series 6 Deck

The Exmark Vertex X-Series VXX999GKA60600 is a premium commercial stand-on mower built for durability, comfort, and maximum productivity. Designed with the same heavy-duty formed and welded tubular steel frame and 15” caster design used on Exmark’s legendary Lazer Z models, the Vertex X-Series is built to handle demanding commercial use with ease.

Powered by Kawasaki engines and equipped with Exmark’s UltraCut deck technology, this mower delivers professional-quality cut performance, excellent efficiency, and smooth operation on both large properties and tighter areas.

The Vertex X-Series is designed for all-day operator comfort with a bolstered operator pad, suspended operator platform, and responsive dual-action controls that provide excellent balance and control. Its wide stance, large 24” drive tires, and heavy-duty 15” semi-pneumatic caster tires improve stability, traction, and ride quality while reducing turf compaction.

Built to minimize downtime, the Vertex X-Series features easy-access service points, a tool-free removable magnetic operator pad, and an open design that simplifies maintenance throughout the season.

Equipment-

Starter:Electric

Steering Control: Twin levers with center fixed reference bar for ease of control forward and reverse

Front Caster Tires: 15 x 6.0-6, smooth-tread, semipneumatic tires with tapered roller bearings.

Drive Tires: 24 x 12-12 Hoosier Grass Master

Parking Brake: Lever-actuated internal motor brake

Tractor Frame: Welded, heavy-duty 1.5" x 3.0" tubular steel.

Blade Spindles: No maintenance, sealed and nongreasable spindles; 7.75" diameter cutter housing with 1.75" diameter splined blade driver 1.0"-diameter spindle shaft.

Cup Holder: Yes

Electrical: 12-volt battery with 30-amp alternator.

Standard Features: Enhanced Engine Hour Meter

Power Components-

Transmission Brand: Hydro-Gear

Transmission Speeds: Infinitely Variable

Engine Brand: Kawasaki

Engine Model: FX1000V

Engine Displacement: 999cc

Transmission: Hydrostatic

Speed: Infinitely variable speed selection 0–12.0 mph forward, 0–5.0 mph reverse

Engine Series: V-Twin

Fuel System: Carbureted

Engine Speed: 3,600 rpm

Fuel Capacity: 14-gallon dual fuel tanks on RH and LH side

Air Filter: Heavy-duty canister air filtration system

Drive Description: Two Hydro-Gear 16 cc pumps powering two Hydro gear 17.8 cubic inch motors.

Fuel Type: Gas Carbureted

PTO Engagement: Warner 250 ft-lb clutch

Fuel Indicator: Float gauge

Drive Wheel Release: Allows unit movement without engine running.

Deck Lift: Single point HOC; with mechanical lift-assist springs.

Carb Compliant: NO

Safety Package: Operator Presence Controls (OPC) with safety interlock system indicators

Deck-

Deck Style: Floating Deck

Deck Style Description: Full-floating UltraCut Series 6. Side discharge standard, with molded discharge chute and option to bag or mulch.

Width / Cutting Deck: 60"

Deck Construction: 10-gauge top that is formed and continuously seam welded, 7-gauge side skirt

Cutting Heights: 1.5" to 5.0" in 0.25" increments

Blade Tip Speed: Approximately 18,500 fpm

Blades: 3 Blades at 20.50" Length

Warranty: 5-year or 1500 hr(no hour limit in the first 2 years)
